GMA
GMA300F series
Cosel
300W Medical Single Output AC/DC Switch Mode Compact 2x4
- Optional parts
- Datasheet
- Manual
- Application manual
- RoHS declaration
- RoHS declaration
Datasheet
Manual
Declaration
Compact 300 W medical grade AC/DC power supply. Designed for BF application with 2MOPP in a 2"x4" mechanical footprint. Efficiency up to 93% and with additional features such as remote on/off and auxiliar outputs.
Product features
High electric power density : 25.7W/inch3
High efficiency : 93％ typ (Input Voltage 230V, Output Voltage 24V)
For medical electric equipment (ANSI/AAMI ES60601-1, EN60601-1 3rd, IEC60601-1-2 4th Ed.)
Design for BF application (Output-FG : 1MOPP, Input-Output : 2MOPP)
2"× 4"standard footprint
With Remote (Optional)
With AUX1 (12V), AUX2 (5V) (Optional)
GMA300F series models
| Model # | Input voltage AC | Input voltage DCnom (min-max) |
Output power | Outputs Vnom (min-max) | Outputs A max |
|---|---|---|---|---|---|
| GMA300F-12 | 110/230VAC | N/A | 300W | Output 1: 12 (12 to 12)VDC | Output 1: 25A |
| GMA300F-24 | 110/230VAC | N/A | 300W | Output 1: 24 (24 to 24)VDC | Output 1: 12.5A |
| GMA300F-48 | 110/230VAC | N/A | 302W | Output 1: 48 (48 to 48)VDC | Output 1: 6.3A |
| GMA300F-56 | 110/230VAC | N/A | 302W | Output 1: 56 (56 to 56)VDC | Output 1: 5.4A |
